Specifications
Please note - specifications subject to change without prior notice.
| FRAME | All New Series 4 Alloy, 180mm travel MultiTrac LT Suspension, Adjustable CS Length/BB Height, 27.5" or 29" compatible, 148mm, Rear Thru-Axle, & frame protection, UDH |
| FRONT SUSPENSION | RockShox Boxxer, 200mm Travel, 29" , 110x20mm Maxle Stealth, 52mm Offset |
| REAR SUSPENSION | RockShox Vivid Coil Ultimate DH, 22x5x75mm Trunnion Upper Mount, 30xM8 Lower Mount, Custom Tune |
| RIM | 32H, Tubeless Compatible |
| HUB REAR | Marin Forged, 110x20mm, 6-Bolt Disc, 32H |
| HUB FRONT | Formula, DDL-348S, 148x12mm, 6-Bolt Disc, 32H, Shimano Freehub Body |
| SPOKES | 14g Black Stainless Steel |
| TIRES | Maxxis Assegai, 2.5", Tubeless Ready, 3C MaxxGrip, DH Casing |
| CHAINGUIDE | e*thirteen Vario DH Chainguide |
| DERAILLEUR REAR | SRAM GX DH |
| SHIFT LEVER | SRAM GX DH, 7-Speed |
| CRANKSET | SRAM Descendant Alloy 34T, 165mm |
| BOTTOM BRACKET | SRAM DUB BSA |
| CHAIN | SRAM PC-1110 |
| CASSETTE | SRAM GS DH, 11-25T |
| BRAKES FRONT | SRAM Maven Bronze, 200mm HS2 Rotor |
| BRAKES REAR | SRAM Maven Bronze, 200mm HS2 Rotor |
| BRAKE LEVERS | SRAM Maven Bronze, SRAM Descendant DH, 31.8mm Clamp, 25mm Rise, 9 Degree |
| HANDLEBAR | SRAM Descendant DH, 31.8mm Clamp, 25mm Rise, 9 Degree Backsweep, 5 Degree Upsweep |
| STEM | SRAM Descendant DH Direct Mount, 31.8mm Clamp, 50mm Length |
| GRIPS | Marin Grizzly Lock-On |
| HEADSET | FSA No 74 |
| SEATPOST | Marin Alloy, 34.9mm |
| SADDLE | Marin Short Nose |
| PEDALS | - |
| EXTRAS | Downtube & Shuttle Guards |
